– Eight 10/100 Mbps LAN ports

Standards

– IEEE 802.3 10BASE-T

– IEEE 802.3u 100BASE-TX

– IEEE 802.3x Flow Control

– IEEE 802.3az Energy-Efficient Ethernet (EEE)

Switching Capacity

– 1.6 Gbps switching fabric

Advanced Features

– Auto MDI/MDIX crossover for all ports

– Secure store-and-forward switching scheme

– Full/half-duplex for Ethernet/Fast Ethernet speeds

– Supports 2,048 byte jumbo frames

– Back pressure at half-duplex operation

– Wire-speed reception and transmission

– Store and-Forward switching method

– Auto-negotiation for each port

– EEE compliant IEEE 802.3 10BASE-T

– IEEE 802.3u 100BASE-TX

– IEEE 802.3az EEE

– IEEE 802.3x flow control

Data Transfer Rates

– Ethernet:

– 10 Mbps (half duplex)

– 20 Mbps (full duplex)

– Fast Ethernet:

– 100 Mbps (half duplex)

– 200 Mbps (full duplex)

Transmission Method

– Store-and-forward

MAC Address Table Size

– 2,000

Packet Filtering/Forwarding Rates

– Ethernet: 14,880 pps per port

– Fast Ethernet: 148,800 pps per port

RAM Buffer

– 96 KB per device

– Per port: Link/Activity/Speed

– Per device: Power
Media Interface Exchange

– Auto MDI/MDIX adjustment for all ports
Dimensions

– 131 x 54 x 21 mm
Weight

– 74.8 grams
Power

– DC 5 V / 0.55 A

– DC jack: Located on side
Power Consumption

– Power On (Standby): 0.55 watts

– Maximum: 1.55 watts
Temperature

– Operating: 0° to 40°C

– Storage: -40° to 70°C
Humidity

– Operating: 10% to 90% (Non-condensing)

– Storage: 5% to 95% (Non-condensing)
MTBF

– 1 579 582 hours
Maximum Heat Dissipation

– 0.691 BTU/h
Certifications

– CE Class B

– CE (LVD 2006/95/EC)
